Input voltage: AC100V~240V 50/60Hz
Fuse: BGDP φ5x20mm 6.3A/250VAC
Laser specifications: R：12w/638nm
G：14w/520nm
B：24w/450nm
Laser output power: 50W
Modulation method: Analog modulation
Total power: 500W
Control mode: self-propelled DMX512、 Master and slave 、ILDA
Scanning system: 30K galvanometer
Scanning angle: ± 20 °
Channel mode: 12CH、14CH、16CHFB4、18CH、27CH、29CH
Working temperature: -10℃~40℃
Cooling mode: air-cooled cooling
Net weight: 33KG
Protection level: IP65
Chassis size: 52.7 × 51.5 × 43.2CM
