Light Source
Light Source: 40 × 40W RGBW LEDs
Color Temperature: 6500K-7000K
Lifespan: 50,000 hours
Optical System
Lens Angle: 40°
Control & Programming
Control Interface: 4 touch buttons
Display: LCD screen
Control Protocol: DMX / Auto / RDM / Art-Net
Channel Modes: 9CH / 15CH / 160CH / 163CH / 175CH
Software Upgrade: Via DMX connection
Electrical & Connectors
Input Voltage: AC100-240V ~ 50/60Hz
Power Consumption: 1280W
Power Connector: Waterproof "PowerPASS" Input/Output
DMX Connector: Waterproof 3-pin XLR "DataPASS"
Network Port: RJ45 Input/Output
Physical Specifications
Dimensions: 510 × 92.5 × 440 mm (20.08 × 3.64 × 17.32 in)
Net Weight: 19 kg (41.88 lbs)
Environmental Ratings
IP Rating: IP65
Max. Operating Temperature: 45°C
Min. Operating Temperature: -10°C
